water jet Weaving loom manufacturers
New type sturdy double-sided box frame reduces vibration at high-speed operation.Because of this reduces vibration, the filing insertion and the beating motion are much more stabilized which keeps fabric quality high. It’s main drive is contained in an oil bath to achieve stable high-speed operation. New type nozzle also realized the filing insertion with high speed and stability.
|
Reed Space(CM) |
135,150,170,190,210,230,260,280,300,320,340,350,360 |
|
|
Useful reed space(CM) |
Norminal R/S minus 2cm to 50cm |
|
|
Frame |
Box frame type Driving section is in oil bath |
|
|
Driving |
Brake |
Direct stop mechanism by an electromagnetic brake |
|
|
Controller |
Push and touch button(Arrange,stop,forward,brake,reverse) |
|
|
Motor |
Rush start motor |
|
|
Motor power |
1.5kw,1.8kw,2.2kw,2.7kw,3.2kw,3.7kw,4.5kw,5.4kw |
|
Beating |
Crank beating |
|
|
Let off |
system |
Automatic mechanical and continuous let-off;Or electronic let-off,One or vertical two roll |
|
|
warp beam |
Φ800mm flange，Φ178mm barrel |
|
Take up |
system |
Mechanical or electronic continuous take-up |
|
|
Pick density |
Normal:5-60picks/cm;Special:4-100picks/cm |
|
|
Cloth wind-up diameter |
Φ420mm,Φ520mm,Φ600mm |
|
Shedding |
Plain shedding |
crank shedding(heald frame 2 to 8；1/1 fabric |
|
|
Cam shedding |
Cam shedding(heald frame 2 to 14);Plain,twill,satin babric |
|
|
Dobby shedding |
Positive/negative(heald frame 16 max.);Electronic and mechanical reading system;Plain,twill,sation or complex design |
|
|
Jaquard |
1408,2688,5120 lifting hooks;electronic jacquard device |
|
Weft insertion |
Measuring and storage |
300#RDP type mechanical measuring turbo blower(single nozzle)Or electronic weft feeder(1-6nozzles) |
|
|
Pump |
M,L,H type, Single or Double |
|
|
Plunger |
Ceramic plunger;Φ32/Φ17,Φ32/Φ18,Φ32/Φ20,Φ36/Φ22,Φ36/Φ24,Φ36/Φ26,Φ39/Φ26,Φ39/Φ28,Φ39/Φ30,Φ50/Φ35 |
|
|
Nozzle needle |
ST20/10;ST30/10;ST45/20,SD75/40 |
|
|
Weft filling |
1/2/3/4/6 nozzle |
|
|
Filling feeder |
Electronic,optical,and self-control |
|
Selvage/Leno system |
Twisting by star,planetary gears |
|
|
Electrical part |
Made in china /import |
Main control board,AC contactor,transformer,NC interface,Selvagebrake system,Waste yarn brake system,overheating and overload protection |
|
|
Electronic meter |
count and display,rotational speed,total yield,team yield,total efficiency,team efficiency,cloth length auto control,stopping analysis and display |
|
Other devices |
take up roller-one;weft density gear-one;Trashcan-one;nozzle needle-one set |
|
1.Energy-saving Mechanism
Motor X has been desinged to be easily connected to the main axle.The mechanism components like beeak disc,pulley and the belt can be saved to lower the cost and reduce the kinetic energy loss owing to its direct drive axle structure.As a result,the energy saving rate of the whole scheme reaches to 15%-25%compared to the original type of looms.
2.Reliability
The SHT high temperature resistant magnet(up tp 150℃）was adopted in our motor X series in order to prevent the machine from the risk of degaussing.
The excellent sealing technology owned by us perfectly protect the weaving machine from the high humidity enviroment.
3.Energy Saving
The energy saving rate of the motor X is 15%-25%,which is equivalent to saving about $500usd per year and $48000 per 1000 water jet looms.It also makes it possible to have more equipment working at the same time under the same rated transformer.
4.Reducing Machinery Cost
Compared with the traditional AC asynchronous motor,the direct drive system saves the component cost of the motor,brake dics,belt and pulley,and has its own frequency conversion function,which is equivalent to and additionally saves the cost of installing frequency conversion.
5.Saving Labor Cost
The speed of the water jet looms can be changed freely to achive the efficient switching between different varieties and continuously improving the speed.Saving human cost.
6.Safety
Slow inching function can efficiency reduce the wear of the looms and protect he operators at the same time.
7.Improving Fabric Quality
To ensure the quality of the products,certain kinds of fabric may require a fixed angle to start-stop.Motor X series allows the loom to achieve this goal by meeting this technological requirements automatically.Even those workers who lack skills and experience can effectively control fabric quality.Reducing the rate of rags and production cost.
8.Increasing Output
The speed of the water jet looms can be changed freely to achieve the efficient switching between different varieties and continuously improving the speed.Increasing the output for weaving factory.
Our customers come from all over the world, the main markets are in India, Indonesia, etc.
What are your price?
Our prices are subject to change depending on supply and other market factors. We will send you an updated price list after your company contact us for further information.
Do you have a minimum order quantity?
The MOQ is 1 set, but usually we sell by the full container.
What about machine quality guarantee period?
Frames 1 year guarantee, easy damaged parts 3 months guarantee, and also we will give away free accessories according to the order quantity.
What terms of payment are acceptable to you?
You can make the payment to our bank account,usually 30% deposit and 70% payment before delivery by T/T.
Where is your factory located? How can l visit there?
Our factory is located in Jiaozhou, Qingdao city. You can fly directly to Qingdao airport. We warmly welcome all customers at home and abroad to visit and guide!
